Features Descriptions M6100 Broadcast Satellite Modulator
12.1.6 Spectrum Polarity
M6100 >> Modulator >> Spectrum Polarity
Spectrum inversion can be enabled in case an inverting upconverter is used. As a general rule
transmissions on satellite need to be non-inverted.
Most modern demodulators can detect and automatically adapt the spectrum
inversion.
12.1.7 Output Level
M6100 >> Modulator >> Output Level
The output level must be set according to the network requirements.
For L-band the range is between -35/+7 dBm (± 2dB)
For IF-band the range is between -35/+10 dBm (± 2 dB);
The step size is 0.1dB.
12.1.8 Carrier Modulation
M6100 >> Modulator >> Carrier Modulation
This command controls the carrier modulation:
• On (Operational modulated carrier signal);
• Pure Carrier (unmodulated output signal);
• Test modulation (pulse);
• Test modulation (clock/4);
• Test modulation (clock/8);
• Test modulation (clock/16).
