Appendix A - Alarm List M6100 Broadcast Satellite Modulator
14.2 Ethernet Interface Alarms
Alarm Description
Eth Data Link Failure This alarm is raised when there is no signal on the
corresponding Ethernet interface.
Eth Data Itf Failure This alarm is raised when a failure is detected on the
Ethernet interface.
Eth Mgmt Link Failure This alarm is raised when there is no signal on the
corresponding Ethernet interface.
Eth Mgmt Itf Failure This alarm is raised when a failure is detected on the
Ethernet interface.
Eth Mgmt Fp Link Failure This alarm is raised when there is no signal on the
corresponding Ethernet interface. (Front Panel)
Eth Data Half Duplex This alarm is raised when an Ethernet interface is in half
duplex mode as a result of a link negotiation.
The alarm is not raised when the Ethernet interface was
forced in half duplex mode by configuration on the device.
