9.5.12 Parameters in the GUI
The GUI contains different types of parameter dialogue boxes to configure all parameters.
Dialogue box
Type
Example
Drop-down-list-box
Edit
This pencil icon indicates that it is possible to edit the parameter
Lock
The lock icon indicates that it is not possible to edit the parameter.
Data field
Check box
• To apply a setting use the following icon .
• To cancel a setting use the following icon
Table
Functional group
Enable/Disable
button
Enabled
(indication)
Disabled
(indication)
Reset button
