Appendix A - Alarm List M6100 Broadcast Satellite Modulator
14.1 Generic Alarms
Alarm Description
Temperature This alarm is raised when the monitored temperature
exceeds 85 °C.
General Device This alarm can be triggered by one of the following alarms:
• Modulator DAC Failure;
• Modulator No Calibration Data;
• Invalid License;
• Boot Config Failure;
• Temperature;
• Modulator Ref synthesizer failure alarm;
• Modulator LO-1 synthesizer failure alarm;
• Modulator LO-2 synthesizer failure alarm.
General Interface This alarm is raised when an error is reported on an interface
that is used in the data path.
This alarm can be triggered by one of the following alarms:
• Ethernet interface alarm.
• Ref Clock No Signal;
• S2 EXT Demodulator No Lock;
• S2 EXT Demodulator Incompatible Baseband Frame;
• DVB Demodulator No Lock.
Invalid License This alarm is raised when the license file is not available or
wrongly signed.
Boot Config Failure This alarm is raised when an erroneous boot configuration
was attempted to load and failed.
Check the boot configuration file stored on the device.
Frontpanel Internal Failure This alarm is raised when the front panel communication
failed.
