Drawers 7-11
Installation Procedures
10. Insert the spacer bracket between the left carrier bracket and the frame.
Figure 7-11. Insert the hinge bracket between the left carrier wall and the frame
11. Secure the left carrier wall to the frame with two screws using a Torx T15 screwdriver.
Figure 7-12. Secure the left carrier wall to the frame
