8-4 Drawer Connect Board
Removal Procedure
1-, 2-, 3-Cell Color Touch Installation and Service Guide/67-2014 Rev G © 2011 Omnicell, Inc.
9. Disconnect the drawer cables from the drawer connect board.
Figure 8-6. Disconnect the Drawer Cable from the Drawer Connect Board
10. Remove the SPC to drawer connect board cables.
Figure 8-7. Remove the SPC to Drawer Connect Board Cables
