© 2011 Omnicell, Inc. 1-, 2-, 3-Cell Color Touch Installation and Service Guide/67-2014 Rev G
Manual Override 9-3
Removal Procedure
7. Remove all slide support brackets.
Figure 9-4. Remove the Slide Support Brackets
8. Remove the screws securing the top cover to the frame, one on each side of the carrier.
Figure 9-5. Remove the screws securing the top cover to the frame
9. Remove the top cover.
To Next Page
