Omron 3G3RX - Page 313

4-194
4-4 Communication Function
4
Functions
1307h
Frequency matching lower
limit frequency setting
b007
(HIGH)
R/W
0.00 to 400.00
0.01
[Hz]
1308h
b007
(LOW)
R/W
1309h Trip retry selection b008 R/W
00: TRIP (Alarm)
01: 0-Hz start
02: f-match (Frequency matching start)
03: f-match Trip (Trip after frequency
matching deceleration stop)
04: Actv. f-match (Active Frequency
Matching restart)

130Ah
Undervoltage retry time
selection
b009 R/W
00: 16 times
01: No limit

130Bh
Overvoltage/overcurrent
retry time selection
b010 R/W 1 to 3 
130Ch Trip retry wait time b011 R/W 0.3 to 100.0 0.1 [s]
130Dh Electronic thermal level b012 R/W
0.20 x Rated current to 1.00 x Rated
current
0.1 [A]
130Eh
Electronic thermal
characteristics selection
b013 R/W
00: Reduced TRQ (Reducted torque
characteristics)
01: Const TRQ (Constant torque
characteristics)
02: Free set (Free setting)

130Fh Not used  
1310h
Free setting, electronic
thermal frequency 1
b015 R/W 0 to 400 1 [Hz]
1311h
Free setting, electronic
thermal current 1
b016 R/W 0.0 to Rated current 0.1 [A]
1312h
Free setting, electronic
thermal frequency 2
b017 R/W 0 to 400 1 [Hz]
1313h
Free setting, electronic
thermal current 2
b018 R/W 0.0 to Rated current 0.1 [A]
1314h
Free setting, electronic
thermal frequency 3
b019 R/W 0 to 400 1 [Hz]
1315h
Free setting, electronic
thermal current 3
b020 R/W 0.0 to Rated current 0.1 [A]
1316h Overload limit selection b021 R/W
00: OFF (Disabled)
01: ON-Acc/Cnst (Enabled in
acceleration/constant speed
operation)
02: ON-Cnst (Enabled during constant
speed operation)
03: ON-A/C (R) (Enabled in acceleration/
constant speed operation
(accelerates during regeneration))

1317h Overload limit level b022 R/W
0.20 x Rated current to 2.00 x Rated
current (0.4 to 55 kW)
0.20 x Rated current to 1.80 x Rated
current (75 to 132 kW)
0.1 [A]
1318h Overload limit parameter b023 R/W 0.10 to 30.00 0.01 [s]
Register
No.
Function name
Function
code
R/W Monitor and setting parameters
Resolu-
tion
