Omron 3G3RX - Page 317

4-198
4-4 Communication Function
4
Functions
1348h Not used  
1349h
Analog operation level at
O disconnection
b070 R/W 0 to 100/no (ignored) 1 [%]
134Ah
Analog operation level at
OI disconnection
b071 R/W 0 to 100/no (ignored) 1 [%]
134Bh
Analog operation level at
O2 disconnection
b072 R/W -100 to 100/no (ignored) 1 [%]
134Ch
to
1350
Not used  
1351h Integrated power clear b078 R/W
Cleared with the Enter key after changing
to 01

1352h
Integrated power display
gain
b079 R/W 1 to 1000 1
1353h Not used  
1354h Not used  
1355h Starting frequency b082 R/W 0.10 to 9.99
0.01
[Hz]
1356h Carrier frequency b083R/W
0.5 to 15.0 (0.4 to 55 kW)
0.5 to 10.0 (75 to 132 kW)
0.1 [kHz]
1357h Initialization selection b084R/W
00: no (Clears the trip monitor)
01: Trip data (Initializes data)
02:
Parameters (Clears the trip monitor
and initializes data)
03: Trip+Param (Clears the trip monitor
and parameters)
04: Trp+Prm+EzSQ (Clears the trip moni-
tor, parameters and Drive Program)

1358h
Initialization parameter
selection
b085R/W
01
*Do not change.

1359h
Frequency conversion
coefficient
b086 R/W 0.1 to 99.9 0.1
135Ah STOP key selection b087R/W
00: ON (Enabled)
01: OFF (Disabled)
02: Only RESET (Disabled only during
stop)

135Bh Free-run stop selection b088 R/W
00: 0-Hz start
01: f-match (Frequency matching start)
02: Actv. f-match (Active Frequency
Matching restart)

135Ch
Automatic carrier
reduction
b089R/W
00: OFF (Disabled)
01: ON (Enabled)

135Dh
Usage rate of regenerative
braking function
b090 R/W 0.0 to 100.0 0.1 [%]
135Eh Stop selection b091 R/W
00: Decel-Stop (Deceleration  Stop)
01: Free-RUN (Free-run stop)

135Fh Cooling fan control b092 R/W
00: Alws-ON (Always ON)
01: ON in RUN (ON during RUN)

1360h Not used  
1361h Not used  
Register
No.
Function name
Function
code
R/W Monitor and setting parameters
Resolu-
tion
