Omron 3G3RX - Page 316

4-197
4-4 Communication Function
4
Functions
1339h
Deceleration starting width
of non-stop function at
momentary power
interruption
b054 R/W 0.00 to 10.00
0.01
[Hz]
133Ah
Proportional gain setting of
non-stop function at
momentary power
interruption
b055 R/W 0.00 to 2.55 0.01
133Bh
Integral time setting of
non-stop function at
momentary power
interruption
b056 R/W 0.000 to 65.535 0.001 [s]
133Ch
to
133Eh
Not used  
133Fh
Window comparator O
upper limit level
b060 R/W
Set an upper limit level.
Setting range: 0 to 100
Lower limit: Lower limit level + Hysteresis
width × 2
1 [%]
1340h
Window comparator O
lower limit level
b061 R/W
Set a lower limit level.
Setting range: 0 to 100
Upper limit: Upper limit level - Hysteresis
width × 2
1 [%]
1341h
Window comparator O
hysteresis width
b062 R/W
Set a hysteresis width for the upper and
lower limit levels.
Setting range: 0 to 10
Upper limit: (Upper limit level - Lower limit
level) × 2
1 [%]
1342h
Window comparator OI
upper limit level
b063 R/W
Set an upper limit level.
Setting range: 0 to 100
Lower limit: Lower limit level + Hysteresis
width × 2
1 [%]
1343h
Window comparator OI
lower limit level
b064 R/W
Set a lower limit level.
Setting range: 0 to 100
Upper limit: Upper limit level - Hysteresis
width × 2
1 [%]
1344h
Window comparator OI
hysteresis width
b065 R/W
Set a hysteresis width for the upper and
lower limit levels.
Setting range: 0 to 10
Upper limit: (Upper limit level - Lower limit
level) × 2
1 [%]
1345h
Window comparator O2
upper limit level
b066 R/W
Set an upper limit level.
Setting range: -100 to 100
Lower limit: Lower limit level + Hysteresis
width × 2
1 [%]
1346h
Window comparator O2
lower limit level
b067 R/W
Set a lower limit level.
Setting range: -100 to 100
Upper limit: Upper limit level - Hysteresis
width × 2
1 [%]
1347h
Window comparator O2
hysteresis width
b068 R/W
Set a hysteresis width for the upper and
lower limit levels.
Setting range: 0 to 10
Upper limit: (Upper limit level - Lower limit
level) × 2
1 [%]
Register
No.
Function name
Function
code
R/W Monitor and setting parameters
Resolu-
tion
