4-204
4-4 Communication Function
4
Functions
141Bh FM selection C027 R/W
00: Output FQ (Output frequency)
01: Output I (Output current)
02: Output TRQ (Output torque)
03: Pulse FQ (Digital output frequency)
04: Output V (Output voltage)
05: Power
06: Thermal (Thermal load rate)
07: LAD-FQ (LAD frequency)
08: Pulse I (Digital current monitor
)
09: Motor tmp (Motor temperature)
10: Heatsink tmp (Fin temperature)
12: YA0 (Drive Programming)
19: OP1 (Option board 1)
20: OP2 (Option board 2)

141Ch AM selection C028 R/W
00: Output FQ (Output frequency)
01: Output I (Output current)
02: Output TRQ (Output torque)
04: Output V (Output voltage)
05: Power
06: Thermal (Thermal load rate)
07: LAD-FQ (LAD frequency)
08: Pulse I (Digital current monitor)
09: Motor tmp (Motor temperature)
10: Heatsink tmp (Fin temperature)
11: Out TRQ sign (Output torque
(signed))
13: YA1 (Drive Programming)
19: OP1 (Option board 1)
20: OP2 (Option board 2)

141Dh AMI selection C029 R/W
00: Output FQ (Output frequency)
01: Output I (Output current)
02: Output TRQ (Output torque)
04: Output V (Output voltage)
05: Power
06: Thermal (Thermal load rate)
07: LAD-FQ (LAD frequency)
09: Motor tmp (Motor temperature)
10: Heatsink tmp (Fin temperature)
14: YA2 (Drive Programming)

141Eh
Digital current monitor
reference value
C030 R/W
0.20 × Rated current to
2.00 × Rated current (Under 55 kW)
0.20 × Rated current to
1.50 × Rated current (Over 75 kW)
(Current value at the digital current
monitor output 1440 Hz)
0.1 [A]
Register
No.
Function name
Function
code
R/W Monitor and setting parameters
Resolu-
tion
