4-205
4-4 Communication Function
4
Functions
141Fh
Multi-function output
terminal 11 contact
selection
C031 R/W
00: NO
01: NC

1420h
Multi-function output
terminal 12 contact
selection
C032 R/W 
1421h
Multi-function output
terminal 13 contact
selection
C033 R/W 
1422h
Multi-function output
terminal 14 contact
selection
C034 R/W 
1423h
Multi-function output
terminal 15 contact
selection
C035 R/W 
1424h
Relay output (AL2, AL1)
contact selection
C036 R/W
00: NO contact at AL2, NC contact at AL1
01: NC contact at AL2, NO contact at AL1

1425h Not used  
1426h
Light load signal output
mode
C038 R/W
00: ACC/DEC/CST (Enabled during
acceleration/deceleration/constant
speed)
01: Const (Enabled only during constant
speed)

1427h Light load detection level C039 R/W
0.0 to 2.00 x Rated current (0.4 to 55 kW)
0.0 to 1.80 x Rated current (75 to 132 kW)
0.1 [A]
1428h
Overload warning signal
output mode
C040 R/W
00: ACC/DEC/CST (Enabled during
acceleration/deceleration/constant
speed)
01: Const (Enabled only during constant
speed)

1429h Overload warning level C041 R/W
0.0: Does not operate.
0.1 x Rated current to 2.00 x Rated
current (0.4 to 55 kW)
0.1 x Rated current to 1.80 x Rated
current (75 to 132 kW)
0.1 [A]
142Ah
Arrival frequency during
acceleration
C042
(HIGH)
R/W
0.00 to 400.00
0.01
[Hz]
142Bh
C042
(LOW)
R/W
142Ch
Arrival frequency during
deceleration
C043
(HIGH)
R/W
0.00 to 400.00
0.01
[Hz]
142Dh
C043
(LOW)
R/W
142Eh
PID deviation excessive
level
C044 R/W 0.0 to 100.0 0.1 [%]
142Fh
Arrival frequency during
acceleration 2
C045
(HIGH)
R/W
0.00 to 400.00
0.01
[Hz]
1430h
C045
(LOW)
R/W
Register
No.
Function name
Function
code
R/W Monitor and setting parameters
Resolu-
tion
