4-206
4-4 Communication Function
4
Functions
1431h
Arrival frequency during
deceleration 2
C046
(HIGH)
R/W
0.00 to 400.00
0.01
[Hz]
1432h
C046
(LOW)
R/W
1433h
to
1437h
Not used  
1438h PID FB upper limit C052 R/W 0.0 to 100.0 0.1 [%]
1439h PID FB lower limit C053 R/W 0.0 to 100.0 0.1 [%]
143Ah Not used  
143Bh
Overtorque level
(Forward power running)
C055 R/W
0 to 200 (0.4 to 55 kW)
0 to 180 (75 to 132 kW)
1 [%]
143Ch
Overtorque level
(Reverse regeneration)
C056 R/W
0 to 200 (0.4 to 55 kW)
0 to 180 (75 to 132 kW)
1 [%]
143Dh
Overtorque level
(Reverse power running)
C057 R/W
0 to 200 (0.4 to 55 kW)
0 to 180 (75 to 132 kW)
1 [%]
143Eh
Overtorque level
(Forward regeneration)
C058 R/W
0 to 200 (0.4 to 55 kW)
0 to 180 (75 to 132 kW)
1 [%]
143Fh Not used  
1440h Not used  
1441h Thermal warning level C061 R/W 0 to 100 1 [%]
1442h Alarm code selection C062 R/W
00: OFF (Disabled)
01: 3-bit
02: 4-bit

1443h 0-Hz detection level C063 R/W 0.00 to 100.00
0.01
[Hz]
1444h Fin overheat warning level C064 R/W 0 to 200 1 [
C]
1445h
to
144Ah
Not used  
144Bh
Communication speed
selection
(Baud rate selection)
C071 R/W
02: Loop-back test
03: 2400 bps
04: 4800 bps
05: 9600 bps
06: 19200 bps

144Ch
Communication station
No. selection
C072 R/W 1 to 247 
144Dh
Communication bit length
selection
C073 R/W
7: 7-bit
8: 8-bit

144Eh
Communication parity
selection
C074 R/W
00: No parity
01: Even
02: Odd

144Fh
Communication stop bit
selection
C075 R/W
1: 1-bit
2: 2-bit

Register
No.
Function name
Function
code
R/W Monitor and setting parameters
Resolu-
tion
