4-207
4-4 Communication Function
4
Functions
1450h
Communication error
selection
C076 R/W
00: Trip
01: Decel-Trip (Trip after deceleration
stop)
02: Ignore
03: Free-RUN (Free-run stop)
04: Decel-Stop (Deceleration stop)

1451h
Communication error
timeout
C077 R/W 0.00 to 99.99 0.01 [s]
1452h Communication wait time C078 R/W 0 to 1000 1 [ms]
1453h
Communication method
selection
C079 R/W
00: ASCII
01: ModBus-RTU

1454h Not used  
1455h O adjustment C081 R/W 0 to 65535 1
1456h OI adjustment C082 R/W 0 to 65535 1
1457h O2 adjustment C083 R/W 0 to 65535 1
1458h Not used  
1459h Thermistor adjustment C085 R/W 0.0 to 1000.0 0.1
145Ah
to
145Eh
Not used  
145Fh Debug mode selection C091 R/W
00
*Do not change

1460h
to
1468h
Not used  
1469h UP/DWN selection C101 R/W
00: Not save (Do not store the frequency
data)
01: Save (Store the frequency data)

146Ah Reset selection C102 R/W
00: ON-RESET (Trip reset at power-on)
01: OFF-RESET (Trip reset at power-off)
02: On in Trip (Enabled only during trip
(Reset at power-on))
03: Trip RESET (Trip reset only)

146Bh
Reset frequency matching
selection
C103 R/W
00: 0-Hz start
01: f-match (Frequency matching start)
02: Actv. f-match (Active Frequency
Matching restart)

146Ch Not used  
146Dh FM gain setting C105 R/W 50 to 200 1 [%]
146Eh AM gain setting C106 R/W 50 to 200 1 [%]
146Fh AMI gain setting C107 R/W 50 to 200 1 [%]
1470h Not used  
1471h AM bias setting C109 R/W 0 to 100 1 [%]
1472h AMI bias setting C110 R/W 0 to 100 1 [%]
1473h Overload warning level 2 C111 R/W
0.0 to 2.00 x Rated current (0.4 to 55 kW)
0.0 to 1.80 x Rated current (75 to 132 kW)
0.1 [A]
Register
No.
Function name
Function
code
R/W Monitor and setting parameters
Resolu-
tion
