Omron 3G3RX - Page 327

4-208
4-4 Communication Function
4
Functions
1474h
to
147Ch
Not used  
147Dh O zero adjustment C121 R/W 0 to 65535 1
147Eh OI zero adjustment C122 R/W 0 to 65535 1
147Fh O2 zero adjustment C123 R/W 0 to 65535 1
1480h
to
1485h
Not used  
1486h Output 11 ON delay C130 R/W
0.0 to 100.0
0.1 [s]
1487h Output 11 OFF delay C131 R/W 0.1 [s]
1488h Output 12 ON delay C132 R/W 0.1 [s]
1489h Output 12 OFF delay C133 R/W 0.1 [s]
148Ah Output 13 ON delay C134 R/W 0.1 [s]
148Bh Output 13 OFF delay C135 R/W 0.1 [s]
148Ch Output 14 ON delay C136 R/W 0.1 [s]
148Dh Output 14 OFF delay C137 R/W 0.1 [s]
148Eh Output 15 ON delay C138 R/W 0.1 [s]
148Fh Output 15 OFF delay C139 R/W 0.1 [s]
1490h Relay output ON delay C140 R/W 0.1 [s]
1491h Relay output OFF delay C141 R/W 0.1 [s]
1492h
Logic output signal 1
selection 1
C142 R/W
Same as C021 to C026
(except LOG1 to LOG6)

1493h
Logic output signal 1
selection 2
C143 R/W
Same as C021 to C026
(except LOG1 to LOG6)

1494h
Logic output signal 1
operator selection
C144 R/W
00: AND
01: OR
02: XOR

1495h
Logic output signal 2
selection 1
C145 R/W
Same as C021 to C026
(except LOG1 to LOG6)

1496h
Logic output signal 2
selection 2
C146 R/W
Same as C021 to C026
(except LOG1 to LOG6)

1497h
Logic output signal 2
operator selection
C147 R/W
00: AND
01: OR
02: XOR

1498h
Logic output signal 3
selection 1
C148 R/W
Same as C021 to C026
(except LOG1 to LOG6)

1499h
Logic output signal 3
selection 2
C149 R/W
Same as C021 to C026
(except LOG1 to LOG6)

149Ah
Logic output signal 3
operator selection
C150 R/W
00: AND
01: OR
02: XOR

149Bh
Logic output signal 4
selection 1
C151 R/W
Same as C021 to C026
(except LOG1 to LOG6)

149Ch
Logic output signal 4
selection 2
C152 R/W
Same as C021 to C026
(except LOG1 to LOG6)

Register
No.
Function name
Function
code
R/W Monitor and setting parameters
Resolu-
tion
