4-218
4-4 Communication Function
4
Functions
2273h
2nd 2-step acceleration/
deceleration selection
A294 R/W
00: 2CH-Terminal (Switched via
multifunction input 09)
01: Preset FQ (Switched by setting)
02: FWD-REV (Enabled only when
switching forward/reverse)

2274h
2nd 2-step acceleration
frequency
A295
(HIGH)
R/W
0.00 to 400.00 0.01 [Hz]
2275h
A295
(LOW)
R/W
2276h
2nd 2-step deceleration
frequency
A296
(HIGH)
R/W
0.00 to 400.00 0.01 [Hz]
2277h
A296
(LOW)
R/W
2278h
to
230Bh
Not used  
230Ch
2nd electronic thermal
level
b212 R/W
0.20 x Rated current to 1.00 x Rated
current
0.1 [A]
230Dh
2nd electronic thermal
characteristics selection
b213 R/W
00: Reduced TRQ (Reduced torque
characteristics)
01: Const TRQ (Constant torque
characteristics)
02: Free set (Free setting)

230Eh
to
2501h
Not used  
2502h
2nd motor parameter
selection
H202 R/W
00: Standard motor parameter
01: Auto-tuning parameter
02: Auto-tuning parameter
(online auto-tuning enabled)

2503h
2nd motor capacity
selection
H203 R/W 0.20 to 160.0 0.01 [kW]
2504h
2nd motor pole number
selection
H204 R/W 2/4/6/8/10 Pole
2505h
2nd speed response
H205
(HIGH)
R/W
0.001 to 80.000 0.001
2506h
H205
(LOW)
R/W
2507h
2nd stabilization
parameter
H206 R/W 0 to 255 1
2508h
to
2514h
Not used  
2515h
2nd motor parameter R1
H220
(HIGH)
R/W
0.001 to 65.535 0.001 []
2516h
H220
(LOW)
R/W
2517h
2nd motor parameter R2
H221
(HIGH)
R/W
0.001 to 65.535 0.001 []
2518h
H221
(LOW)
R/W
Register
No.
Function name
Function
code
R/W Monitor and setting parameters Resolution
