Omron 3G3RX - Page 401

App-6
Appendix-1 Parameter List
Appendix
Analog input, Others
A006
O2 selection
[O2 Select]
00: [O2] only
01: [O/OI-P] auxiliary frequency reference
(not reversible)
02: [O/OI-PM] auxiliary frequency reference
(reversible)
03: [OFF] O2 disabled
03 No 
4-12
A011
O start frequency
[[O] start FQ]
0.00 to 400.00 0.00 No Hz
4-14
A012
O end frequency
[[O] end FQ]
0.00 to 400.00 0.00 No Hz
A013
O start ratio
[[O] start %]
0 to 100 0 No %
A014
O end ratio
[[O] end %]
0 to 100 100 No %
A015
O start selection
[[O] start FQ select]
00: External start frequency
(A011 set value)
01: 0 Hz
01 No 
A016
O, O2, OI sampling
[Analog-in filter]
1 to 30
31 (with 500 ms filter ± 0.1 Hz hysteresis)
31 No  4-15
A017
Drive Programming
(EzSQ) Selection
[EzSQ select]
0: Disable
1: [PRG] start
2: Always ON
00 No 
Multi-step speed, Jogging
A019
Multi-step speed
selection
[Multispeed select]
00: Binary: 16-step selection with 4 terminals
01: Bit: 8-step selection with 7 terminals
00 No  4-16
A020
Multi-step speed
reference 0
[Multispeed 0]
0.00 to Max. Frequency [A004] 6.00 Yes Hz
4-8
4-16
A220
* 2nd multi-step
speed reference 0
[Multispeed 0-M2]
0.00 to Max. Frequency [A204] 6.00 Yes Hz
A320
* 3rd multi-step speed
reference 0
[Multispeed 0-M3]
0.00 to Max. Frequency [A304] 6.00 Yes Hz
Parameter
No.
Function name Monitor or data range
Default
setting
Changes
during
operation
Unit Page
* 2nd/3rd control is displayed when "SET(08)/SET3(17)" is allocated to one of multi-function inputs from C001
to C008.
