App-5
Appendix-1 Parameter List
Appendix
Extended Function Mode
Parameter
No.
Function name Monitor or data range
Default
setting
Changes
during
operation
Unit Page
Basic setting
A001
Frequency reference
selection
[Frequency source]
00: VR (Digital Operator (FREQ adjuster))
(Enabled when 3G3AX-OP01 is used.)
01: Terminal
02: Digital Operator (F001)
03: RS485 (ModBus communication)
04: Option 1
05: Option 2
06: Pulse train frequency
07: EzSQ (Drive programming)
10: (Math) Operation function result
01 No 
4-10
4-144
A002
RUN command
selection
[RUN cmd source]
01: Terminal
02: Digital Operator (F001)
03: RS485 (ModBus communication)
04: Option 1
05: Option 2
01 No  4-11
A003
Base frequency
[Base Frequency]
30 to Maximum frequency [A004] 50
No Hz
4-11
4-112
A203
* 2nd set base
frequency
[Base Frequency-M2]
30 to 2nd maximum frequency [A204] 50
4-11
A303
* 3rd set base
frequency
[Base Frequency-M3]
30 to 3rd maximum frequency [A304] 50
A004
Maximum frequency
[Max.Frequency]
A003 to 400 50
No Hz 4-12
A204
* 2nd maximum
frequency
[Max.Frequency-M2]
A203 to 400 50
A304
* 3rd maximum
frequency
[Max.Frequency-M3]
A303 to 400 50
Analog input, Others
A005
O/OI selection
[AT Select]
00: [O]/[O2] Switches between O/OI terminal
AT
01: [O]/[O2] Switches between O/O2 terminal
AT
02: [O]/VR Switches between O/FREQ
adjuster via terminal AT
(Enabled only when 3G3AX-OP01 is
used)
03: [OI]/VR Switches between OI/FREQ
adjuster via terminal AT
(Enabled only when 3G3AX-OP01 is
used)
04: [O2]/VR Switches between O2/FREQ
adjuster via terminal AT
(Enabled only when 3G3AX-OP01 is
used)
00 No  4-12
* 2nd/3rd control is displayed when "SET(08)/SET3(17)" is allocated to one of multi-function inputs from C001
to C008.
