App-10
Appendix-1 Parameter List
Appendix
DC injection braking
A051
DC injection braking
selection
[DB enable]
00: OFF (Disabled)
01: ON (Enabled)
02: ON (FQ) (Frequency control [A052 set
value])
00 No 
4-24
4-112
A052
DC injection braking
frequency
[DB Frequency]
0.00 to 400.00 0.50 No Hz
4-24
A053
DC injection braking
delay time
[DB wait time]
0.0 to 5.0 0.0 No s
4-24
A054
DC injection braking
power
[DB force]
0 to 100 (0.4 to 55 kW) 50 No %
0 to 80 (75 to 132 kW) 40 No %
A055
DC injection braking
time
[DB decel time]
0.0 to 60.0 0.5 No s
A056
DC injection braking
method selection
[DB input select]
00: Edge operation
01: Level operation
01 No 
A057
Startup DC injection
braking power
[DB force start]
0 to 100 (0.4 to 55 kW)
0 to 80 (75 to 132 kW)
0No%
A058
Startup DC injection
braking time
[DB time start]
0.0 to 60.0 0.0 No s
A059
DC injection braking
carrier frequency
[DB carrier FQ]
0.5 to 15.0 (0.4 to 55 kW) 5.0 No kHz
0.5 to 10.0 (75 to 132 kW) 3.0 No kHz
Upper/Lower limiter, Jump
A061
Frequency upper limit
[FQ upper limit]
0.00/Frequency lower limit to Max.
Frequency
0.00
No Hz
4-28
A261
* 2nd frequency
upper limit
[FQ upper limit-M2]
0.00/2nd frequency lower limit to 2nd Max.
Frequency
0.00
A062
Frequency lower limit
[FQ lower limit]
0.00/Starting frequency to Frequency upper
limit
0.00
No Hz
A262
* 2nd frequency lower
limit
[FQ lower limit-M2]
0.00/Starting frequency to 2nd frequency
upper limit
0.00
Parameter
No.
Function name Monitor or data range
Default
setting
Changes
during
operation
Unit Page
* 2nd/3rd control is displayed when "SET(08)/SET3(17)" is allocated to one of multi-function inputs from C001
to C008.
