Omron 3G3RX - Page 408

App-13
Appendix-1 Parameter List
Appendix
RUN mode, Acceleration/Deceleration functions
A092
Acceleration time 2
[Accel.time2]
0.01 to 3600.00
10.00
Yes s
4-37
A292
* 2nd acceleration
time 2
[Accel.time2-M2]
10.00
A392
* 3rd acceleration
time 2
[Accel.time2-M3]
10.00
A093
Deceleration time 2
[Decel.time2]
10.00
A293
* 2nd deceleration
time 2
[Decel.time2-M2]
10.00
A393
* 3rd deceleration
time 2
[Decel.time2-M3]
10.00
A094
2-step acceleration/
deceleration
selection
[Acc2/Dec2 sel]
00: 2CH-Terminal (Switched via multi-
function input 09)
01: Preset FQ (Switched by setting)
02: FWD-REV (Enabled only when switching
forward/reverse)
00
No 
A294
* 2nd 2-step
acceleration/
deceleration
selection
[Acc2/Dec2 sel-M2
00
A095
2-step acceleration
frequency
[Acc.1-2 FQ]
0.00 to 400.00
0.00
No Hz
A295
* 2nd 2-step
acceleration
frequency
[Acc.1-2 FQ-M2]
0.00
A096
2-step deceleration
frequency
[Dec.1-2 FQ]
0.00
No Hz
A296
* 2nd 2-step
deceleration
frequency
[Dec. 1-2 FQ-M2]
0.00
A097
Acceleration pattern
selection
[Accel.curve select]
00: Line
01: S-curve
02: U-curve
03: inv.U curve
04: EL-S curve
01 No 
4-38
A098
Deceleration pattern
selection
[Decel. curve select]
01 No 
Parameter
No.
Function name Monitor or data range
Default
setting
Changes
during
operation
Unit Page
* 2nd/3rd control is displayed when "SET(08)/SET3(17)" is allocated to one of multi-function inputs from C001
to C008.
