App-14
Appendix-1 Parameter List
Appendix
External frequency adjustment
A101
OI start frequency
[[OI] start FQ]
0.00 to 400.00
0.00 No Hz
4-14
A102
OI end frequency
[[OI] end FQ]
0.00 No Hz
A103
OI start ratio
[[OI] start %]
0 to OI end ratio 20 No %
A104
OI end ratio
[[OI] end %]
OI start ratio to 100 100 No %
A105
OI start selection
[[OI] start FQ select]
00: Start FQ (Use OI start frequency [A101])
01: 0 Hz
00 No 
A111
O2 start frequency
[[O2] start FQ]
-400.00 to 400.00
0.00 No Hz
4-15
A112
O2 end frequency
[[O2] end FQ]
0.00 No Hz
Ext freq adjustment
A113
O2 start ratio
[[O2] start %]
-100 to O2 end ratio -100 No %
A114
O2 end ratio
[[O2] end %]
O2 start ratio to 100 100 No %
Accel/Decel
A131
Acceleration curve
parameter
[Accel.curve const]
01 (small curve) to 10 (large curve)
02 No 
4-38
A132
Deceleration curve
parameter
[Decel.curve const]
02 No 
Operation frequency
A141
Operation frequency
input A setting
[A-input calc. FQ]
00: Operator (Digital Operator (F001))
01: VR (Digital Operator (FREQ adjuster))
(Enabled when 3G3AX-OP01 is used.)
02: O (Input O)
03: OI (Input OI)
04: Modbus (RS485 communication)
05: Option 1
06: Option 2
07: Pulse (Pulse train frequency)
02 No 
4-41
A142
Operation frequency
input B setting
[B-input calc. FQ]
03 No 
A143
Operator selection
[Calculation symbol]
00: ADD (Addition (A + B))
01: SUB (Subtraction (A - B))
02: MUL (Multiplication (A × B))
00 No 
A145
Frequency addition
amount
[Add frequency]
0.00 to 99.99
100.0 to 400.0
0.00 No Hz
4-41
A146
Frequency addition
direction
[Add direction]
00: ADD (Add A145 value to output
frequency)
01: SUB (Subtract A145 value from output
frequency)
00 No 
Parameter
No.
Function name Monitor or data range
Default
setting
Changes
during
operation
Unit Page
* 2nd/3rd control is displayed when "SET(08)/SET3(17)" is allocated to one of multi-function inputs from C001
to C008.
