App-15
Appendix-1 Parameter List
Appendix
Acceleration/Deceleration
A150
EL-S-curve ratio 1
during acceleration
[EL-S start accel]
0 to 50 10 No %
4-39
A151
EL-S-curve ratio 2
during acceleration
[EL-S end accel]
0 to 50 10 No %
A152
EL-S-curve ratio 1
during deceleration
[EL-S start decel]
0 to 50 10 No %
A153
EL-S-curve ratio 2
during deceleration
[EL-S end decel]
0 to 50 10 No %
Momentary power interruption/Trip restart
b001
Retry selection
[Restart mode UV]
00: TRIP (Alarm)
01: 0 Hz start
02: f-match (Frequency matching start)
03: f-match Trip (Trip after frequency
matching deceleration stop)
04: Actv. f-match (Active Frequency Matching
restart)
00 No 
4-42
b002
Allowable momentary
power interruption
time
[Allowable UV time]
0.3 to 25.0 1.0 No s
b003
Retry wait time
[Retry wait time UV]
0.3 to 100.0 1.0 No s 4-87
b004
Momentary power
interruption/
undervoltage trip
during stop selection
[UV trip on stop]
00: OFF (Disabled)
01: ON (Enabled)
02: Decel-OFF (Disabled during stop and
deceleration stop)
00 No 
4-42
b005
Momentary power
interruption retry time
selection
[No. Of restart UV]
00: 16 times
01: No limit
00 No 
b006
Input phase loss
protection selection
[Phase loss
detection]
00: OFF (Disabled)
01: ON (Enabled)
01 No  4-46
b007
Frequency matching
lower limit frequency
setting
[Restart min. FQ]
0.00 to 400.00 0.00 No Hz
4-42
4-71
4-87
b008
Trip retry selection
[Restart mode OV/
OC]
00: TRIP (Alarm)
01: 0 Hz start
02: f-match (Frequency matching start)
03: f-match Trip (Trip after frequency
matching deceleration stop)
04: Actv. f-match (Active Frequency Matching
restart)
00 No 
4-42
Parameter
No.
Function name Monitor or data range
Default
setting
Changes
during
operation
Unit Page
* 2nd/3rd control is displayed when "SET(08)/SET3(17)" is allocated to one of multi-function inputs from C001
to C008.
