App-25
Appendix-1 Parameter List
Appendix
Others
b120
Brake control
selection
[Brake control sel]
00: OFF (Disabled)
01: ON (Enabled)
00 No 
4-77
b121
Brake wait time for
release
[Brake w.time Rels]
0.00 to 5.00 0.00 No s
b122
Brake wait time for
acceleration
[Brake w.time Accel]
0.00 to 5.00 0.00 No s
b123
Brake wait time for
stopping
[Brake w.time Stop]
0.00 to 5.00 0.00 No s
b124
Brake wait time for
confirmation
[Brake w.time
Confirm]
0.00 to 5.00 0.00 No s
b125
Brake release
frequency
[Brake Release FQ]
0.00 to 400.00 0.00 No Hz
b126
Brake release current
[Brake Release I]
0.0 to 2.00 × Rated current (0.4 to 55 kW)
0.0 to 1.80 × Rated current (75 to 132 kW)
Rated
current
No 
b127
Brake input
frequency
[Braking Frequency]
0.00 to 400.00 0.00 No Hz
b130
Overvoltage
protection function
selection during
deceleration
[Over-V supp.select]
00: OFF (Disabled)
01: V-const (DC voltage kept constant)
02: Accel (Acceleration enabled)
01 No 
4-78
b131
Overvoltage
protection level
during deceleration
[Over-V supp. level]
200-V class: 330 to 390
400-V class: 660 to 780
380/
760
No V
b132
Overvoltage
protection parameter
[Over-V supp.
constant]
0.10 to 30.00 1.00 No s
b133
Overvoltage
protection
proportional gain
setting
[Over-V supp.P-gain]
0.00 to 2.55 0.50 Yes 
b134
Overvoltage
protection integral
time setting
[Over-V supp.I-gain]
0.000 to 65.535 0.060 Yes s
b164
Auto return initial
display
[Auto return init.disp]
00: OFF
01: ON
00 No 
b166
Data Read/Write
selection
[Data R/W select]
00: R/W OK (Read/Write Ok)
01: R/W Protected (Read/Write Protected)
00 No 
Parameter
No.
Function name Monitor or data range
Default
setting
Changes
during
operation
Unit Page
* 2nd/3rd control is displayed when "SET(08)/SET3(17)" is allocated to one of multi-function inputs from C001
to C008.
