App-26
Appendix-1 Parameter List
Appendix
Others
b180
Initialize trigger
[Initialize trigger]
00: No action
01: Initialize
00 No 
Multi-function input terminals
C001
Multi-function input 1
selection
*1
[Input [1] Function]
01: RV (reverse)
02: CF1 (multi-step speed setting binary 1)
03: CF2 (multi-step speed setting binary 2)
04: CF3 (multi-step speed setting binary 3)
05: CF4 (multi-step speed setting binary 4)
06: JG (jogging)
07: DB (external DC injection braking)
08: SET (2nd control)
09: 2CH (2-step acceleration/deceleration)
11: FRS (free-run stop)
12: EXT (external trip)
13: USP (USP function)
14: CS (commercial switch)
15: SFT (soft lock)
16: AT (analog input switching)
17: SET3 (3rd control)
18: RS (reset)
20: STA (3-wire start)
21: STP (3-wire stop)
22: F/R (3-wire forward/reverse)
23: PID (PID enabled/disabled)
24: PIDC (PID integral reset)
26: CAS (control gain switching)
27: UP (UP/DWN function accelerated)
28: DWN (UP/DWN function decelerated)
29: UDC (UP/DWN function data clear)
31: OPE (forced operator)
32: SF1 (multi-step speed setting bit 1)
33: SF2 (multi-step speed setting bit 2)
34: SF3 (multi-step speed setting bit 3)
35: SF4 (multi-step speed setting bit 4)
36: SF5 (multi-step speed setting bit 5)
37: SF6 (multi-step speed setting bit 6)
38: SF7 (multi-step speed setting bit 7)
39: OLR (overload limit switching)
40: TL (torque limit enabled)
41: TRQ1 (torque limit switching 1)
42: TRQ2 (torque limit switching 2)
43: PPI (P/PI switching)
44: BOK (Brake confirmation)
45: ORT (orientation)
46: LAC (LAD cancel)
47: PCLR (position deviation clear)
48: STAT (
pulse train position command input permission
)
50: ADD (frequency addition)
51: F-TM (forced terminal block)
52: ATR (torque command input permission)
53: KHC (integrated power clear)
54: SON (servo ON)
55: FOC (preliminary excitation)
56: MI1 (Drive programming input 1)
57: MI2 (Drive programming input 2)
58: MI3 (Drive programming input 3)
59: MI4 (Drive programming input 4)
60: MI5 (Drive programming input 5)
61: MI6 (Drive programming input 6)
62: MI7 (Drive programming input 7)
63: MI8 (Drive programming input 8)
65: AHD (analog command held)
66: CP1 (position command selection 1)
67: CP2 (position command selection 2)
68: CP3 (position command selection 3)
69: ORL (zero return limit signal)
70: ORG (zero return startup signal)
71: FOT (forward driving stop)
72: ROT (reverse driving stop)
73: SPD (speed/position switching)
74: PCNT (pulse counter)
75: PCC (pulse counter clear)
82: PRG (Drive program start)
no: NO (no allocation)
01
*1
No 4-79
C002
Multi-function input 2
selection
[Input [2] Function]
12
C003
Multi-function input 3
selection
*1
[Input [3] Function]
18
C004
Multi-function input 4
selection
[Input [4] Function]
02
C005
Multi-function input 5
selection
[Input [5] Function]
03
C006
Multi-function input 6
selection
[Input [6] Function]
06
C007
Multi-function input 7
selection
[Input [7] Function]
08
C008
Multi-function input 8
selection
[Input [8] Function]
no
*1.
C001 and C003 are forcibly rewritten into 18 (RS) and 64 (EMR), respectively, when the emergency shutoff
function is enabled (SW1 = ON).
(64 cannot be set optionally.)
When SW1 is turned ON once and then OFF, C003 has no allocations ("no").
Parameter
No.
Function name Monitor or data range
Default
setting
Changes
during
operation
Unit Page
* 2nd/3rd control is displayed when "SET(08)/SET3(17)" is allocated to one of multi-function inputs from C001
to C008.
