App-30
Appendix-1 Parameter List
Appendix
Multi-function output terminal
C031
Multi-function output
terminal 11 contact
selection
[Output [11] actv.
state]
00: NO
01: NC
00
No 4-96
C032
Multi-function output
terminal 12 contact
selection
[Output [12] actv.
state]
C033
Multi-function output
terminal 13 contact
selection
[Output [13] actv.
state]
C034
Multi-function output
terminal 14 contact
selection
[Output [14] actv.
state]
C035
Multi-function output
terminal 15 contact
selection
[Output [15] actv.
state]
C036
Relay output (AL2,
AL1) contact
selection
[Alarm RLY active
state]
00: NO contact at AL2; NC contact at AL1
01: NC contact at AL2; NO contact at AL1
01
Level and output terminal status
C038
Light load signal
output mode
[LOC out mode
select]
00: ACC/DEC/CST (Enabled during
acceleration/deceleration/constant
speed)
01: Const (Enabled only during constant
speed)
01 No
4-106
C039
Light load detection
level
[LOC out level]
0.0 to 2.00 × Rated current (0.4 to 55 kW)
0.0 to 1.80 × Rated current (75 to 132 kW)
Rated
current
No A
C040
Overload warning
signal output mode
[Overload warn
mode]
00: ACC/DEC/CST (Enabled during
acceleration/deceleration/constant
speed)
01: Const (Enabled only during constant
speed)
01 No
4-49
C041
Overload warning
level
[Overload warn level]
0.0: Does not operate.
0.1 × Rated current to 2.00 × Rated current
(0.4 to 55 kW)
0.1 × Rated current to 1.80 × Rated current
(75 to 132 kW)
Rated
current
No A
Parameter
No.
Function name Monitor or data range
Default
setting
Changes
during
operation
Unit Page
* 2nd/3rd control is displayed when "SET(08)/SET3(17)" is allocated to one of multi-function inputs from C001
to C008.
