App-31
Appendix-1 Parameter List
Appendix
Level and output terminal status
C042
Arrival frequency
during acceleration
[FQ arrive accel.1]
0.00 to 400.00 0.00 No Hz
4-98
C043
Arrival frequency
during deceleration
[FQ arrive decel.1]
0.00 to 400.00 0.00 No Hz
C044
PID deviation
excessive level
[PID deviation]
0.0 to 100.0 3.0 No % 4-31
C045
Arrival frequency
during acceleration 2
[FQ arrive accel.2]
0.00 to 400.00 0.00 No Hz
4-98
C046
Arrival frequency
during deceleration 2
[FQ arrive decel.2]
0.00 to 400.00 0.00 No Hz
C052
PID FB upper limit
[PID FBV high limit]
0.0 to 100.0 100.0 No %
4-31
C053
PID FB lower limit
[PID FBV low limit]
0.0 to 100.0 0.0 No %
C055
Overtorque level
(Forward power
running)
[OV-TRQ FW/POW]
0 to 200 (0.4 to 55 kW) 200
No %
4-100
0 to 180 (75 to 132 kW) 180
C056
Overtorque level
(Reverse
regeneration)
[OV-TRQ RV/REG]
0 to 200 (0.4 to 55 kW) 200
No %
0 to 180 (75 to 132 kW) 180
C057
Overtorque level
(Reverse power
running)
[OV-TRQ RVPOW]
0 to 200 (0.4 to 55 kW) 200
No %
0 to 180 (75 to 132 kW) 180
C058
Overtorque level
(Forward
regeneration)
[OV-TRQ FW/REG]
0 to 200 (0.4 to 55 kW) 200
No %
0 to 180 (75 to 132 kW) 180
C061
Thermal warning
level
[E-Thermal warning]
0 to 100 80 No % 4-46
C062
Alarm code selection
[Alarm code output]
00: OFF (Disabled)
01: 3-bit
02: 4-bit
00 No  4-101
C063
0 Hz detection level
[0Hz detection level]
0.00 to 100.00 0.00 No Hz 4-101
C064
Fin overheat warning
level
[Heatsink warning]
0 to 200 120 No C4-105
Parameter
No.
Function name Monitor or data range
Default
setting
Changes
during
operation
Unit Page
* 2nd/3rd control is displayed when "SET(08)/SET3(17)" is allocated to one of multi-function inputs from C001
to C008.
