Output terminal operation function
C144
Logic output signal 1
operator selection
[Log.out 1 operator]
00: AND
01: OR
02: XOR
00
No 4-102
C145
Logic output signal 2
selection 1
[Log.out 2 operand A]
Same as options for C021 to C026
(excluding LOG1 to LOG6)
00
C146
Logic output signal 2
selection 2
[Log.out 2 operand B]
Same as options for C021 to C026
(excluding LOG1 to LOG6)
00
C147
Logic output signal 2
operator selection
[Log.out 2 operator]
00: AND
01: OR
02: XOR
00
C148
Logic output signal 3
selection 1
[Log.out 3 operand A]
Same as options for C021 to C026
(excluding LOG1 to LOG6)
00
C149
Logic output signal 3
selection 2
[Log.out 3 operand B]
Same as options for C021 to C026
(excluding LOG1 to LOG6)
00
C150
Logic output signal 3
operator selection
[Log.out 3 operator]
00: AND
01: OR
02: XOR
00
C151
Logic output signal 4
selection 1
[Log.out 4 operand A]
Same as options for C021 to C026
(excluding LOG1 to LOG6)
00
C152
Logic output signal 4
selection 2
[Log.out 4 operand B]
Same as options for C021 to C026
(excluding LOG1 to LOG6)
00
No 4-102
C153
Logic output signal 4
operator selection
[Log.out 4 operator]
00: AND
01: OR
02: XOR
00
C154
Logic output signal 5
selection 1
[Log.out 5 operand A]
Same as options for C021 to C026
(excluding LOG1 to LOG6)
00
C155
Logic output signal 5
selection 2
[Log.out 5 operand B]
Same as options for C021 to C026
(excluding LOG1 to LOG6)
00
C156
Logic output signal 5
operator selection
[Log.out 5 operator]
00: AND
01: OR
02: XOR
00
C157
Logic output signal 6
selection 1
[Log.out 6 operand A]
Same as options for C021 to C026
(excluding LOG1 to LOG6)
00
C158
Logic output signal 6
selection 2
[Log.out 6 operand B]
Same as options for C021 to C026
(excluding LOG1 to LOG6)
00
C159
Logic output signal 6
operator selection
[Log.out 6 operator]
00: AND
01: OR
02: XOR
00
Parameter
No.
Function name Monitor or data range
Default
setting
Changes
during
operation
Unit Page
* 2nd/3rd control is displayed when "SET(08)/SET3(17)" is allocated to one of multi-function inputs from C001
