Omron 3G3RX - Page 434

App-39
Appendix-1 Parameter List
Appendix
Control parameter
H030
Motor parameter R1
(auto-tuning data)
[M.const R1
(A.Tune)]
0.001 to 65.535
Depends
on the
motor
capacity.
No 
4-111
4-115
H230
* 2nd motor
parameter R1
(auto-tuning data)
[M.const R1-M2
(A.Tune)]
Depends
on the
motor
capacity.
H031
Motor parameter R2
(auto-tuning data)
[M.const R2
(A.Tune)]
0.001 to 65.535
Depends
on the
motor
capacity.
No 
H231
* 2nd motor
parameter R2
(auto-tuning data)
[M.const R2-M2
(A.Tune)]
Depends
on the
motor
capacity.
H032
Motor parameter L
(auto-tuning data)
[M.const L (A.Tune)]
0.01 to 655.35
Depends
on the
motor
capacity.
No mH
H232
* 2nd motor
parameter L
(auto-tuning data)
[M.const L-M2
(A.Tune)]
Depends
on the
motor
capacity.
H033
Motor parameter Io
(auto-tuning data)
[M.const IO (A.Tune)]
0.01 to 655.35
Depends
on the
motor
capacity.
No A
H233
* 2nd motor
parameter Io
(auto-tuning data)
[M.const IO-M2
(A.Tune)]
Depends
on the
motor
capacity.
H034
Motor parameter J
(auto-tuning data)
[M.const J (A.Tune)]
0.001 to 9999.000
Depends
on the
motor
capacity.
No kgm
2
H234
* 2nd motor
parameter J
(auto-tuning data)
[M.const J-M2
(A.Tune)]
Depends
on the
motor
capacity.
Parameter
No.
Function name Monitor or data range
Default
setting
Changes
during
operation
Unit Page
* 2nd/3rd control is displayed when "SET(08)/SET3(17)" is allocated to one of multi-function inputs from C001
to C008.
