Omron 3G3RX - Page 435

App-40
Appendix-1 Parameter List
Appendix
Control parameter
H050
PI proportional gain
[PI P gain]
0.0 to 1000.0
100.0
Yes 
4-89
4-92
H250
* 2nd PI proportional
gain
[PI P gain-M2]
100.0
H051
PI integral gain
[PI I gain]
0.0 to 1000.0
100.0
Yes 
H251
*2nd PI integral gain
[PI I gain-M2]
100.0
H052
P proportional gain
[P gain]
0.01 to 10.00
1.00
Yes 
H252
*2nd P proportional
gain
[P gain-M2]
1.00
H060
Limit at 0 Hz
[0Hz Speed limit]
0.0 to 100.0
100.0
Yes %
4-117
H260
* 2nd limit at 0 Hz
[0Hz Speed limit-M2]
100.0
H061
Boost amount at SLV
startup, 0 Hz
[Bst HiTQ start SLV]
0 to 50
50
Yes %
H261
* 2nd boost amount at
SLV startup, 0 Hz
[Bst HiTQ start SLV-
M2]
50
H070
For PI proportional
gain switching
[PI P gain term.]
0.0 to 1000.0 100.0 Yes 
4-89
H071
For PI integral gain
switching
[PI I gain term.]
0.0 to 1000.0 100.0 Yes 
H072
For P proportional
gain switching
[P gain term.]
0.00 to 10.00 1.00 Yes 
H073
Gain switching time
[Gain switching time]
0 to 9999 100 Yes ms
Parameter
No.
Function name Monitor or data range
Default
setting
Changes
during
operation
Unit Page
* 2nd/3rd control is displayed when "SET(08)/SET3(17)" is allocated to one of multi-function inputs from C001
to C008.
