Section 5 Object Operations 5-2 Creating Fixed Objects
NS-Designer Operation Manual NS-Designer Operation Manual NS-Designer Operation Manual
Property Settings
Fixed object properties are set in the Property Setting Dialog Box for each fixed object.
1. Select the fixed objects for which the properties are to be set.
2. Perform one of the following operations.
Move the cursor to the fixed object for which properties are to be set and double-click the object.
Double-click
After selecting the fixed object, select Settings - Object properties.
After selecting the fixed object, click the right mouse button and select the object properties menu
from the pop-up menu that is displayed. (The menu names differ for each fixed object.)
After selecting the fixed object, press the Enter Key.
3. The dialog box for setting the fixed object properties will be displayed.
Make the settings on each tab page.
4. Make the settings and then click the OK Button.
5-10

Omron NS Specifications

General

Power Supply	24 VDC
Display Size	5.7 to 12.1 inches (depending on the model)
Resolution	320 x 240 to 800 x 600
Touchscreen Type	Resistive
Display Type	TFT LCD
Communication Interfaces	RS-232C, RS-422/485, Ethernet, USB
Memory	Flash memory
Operating Temperature	0 to 50°C (depending on the model)
Storage Temperature	-20°C to 60°C
Protection Rating	IP65 (front panel)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
CPU	Proprietary Omron CPU (performance varies depending on the model)
