Section 5 Object Operations 5-12 Cross-referencing Addresses
NS-Designer Operation Manual NS-Designer Operation Manual NS-Designer Operation Manual
Searching Again
Click the Find Button to re-specify the search range or refresh the data.
Displaying Detailed Functional Object Information
Displays detailed information for the functional objects that use the specified addresses. The following
information is displayed.
Screen page numbers where the functional object is located. •
•
•
•
ID number
Comment
Label
1. Select the addresses for which detailed information is required.
2. Double-click the selected row or click the Details Button.
The Search Result Dialog Box will be displayed.
Jumping to Functional Objects
Jumps to specified functional object screen paste positions.
1. Click a functional object to select it.
2. Double-click the selected row or click the Jump Button.
The screen where the selected functional object is found will be displayed and the functional object
will flash because it is selected.
5-62

Omron NS Specifications

General

Power Supply	24 VDC
Display Size	5.7 to 12.1 inches (depending on the model)
Resolution	320 x 240 to 800 x 600
Touchscreen Type	Resistive
Display Type	TFT LCD
Communication Interfaces	RS-232C, RS-422/485, Ethernet, USB
Memory	Flash memory
Operating Temperature	0 to 50°C (depending on the model)
Storage Temperature	-20°C to 60°C
Protection Rating	IP65 (front panel)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
CPU	Proprietary Omron CPU (performance varies depending on the model)
