Section 6 Programming Macros 6-1 Registering Macros
NS-Designer Operation Manual NS-Designer Operation Manual NS-Designer Operation Manual
The execution conditions that can be selected for each functional object are shown in the following ta-
ble.
Functional object
Touch
ON
Timing
Touch
OFF
Timing
When
Changing
Numeral/
String
Before
Inputting
Numeral/
String
Before
Writing
Numeral/
String
When
Selecting
a List
ON/OFF Buttons Yes Yes No No No No
Word Buttons Yes Yes No No No No
Command Buttons Yes Yes No No No No
Bit Lamp No No Yes No No No
Word Lamp No No Yes No No No
Numeral Displays & Inputs No No Yes Yes Yes No
String Displays & Inputs No No Yes Yes Yes No
Thumbwheel switches No No Yes No Yes No
Text No No No No No No
List Selection No No No No No Yes
Level Meter No No No No No No
Broken-line Graph No No No No No No
Bitmap No No No No No No
Analogue Meter No No No No No No
Video Display No No No No No No
Date No No No No No No
Time No No No No No No
Data Log Graph No No No No No No
Data Block Table No No No Yes Yes No
Temporary Input No No No No No No
Alarm/Event Objects
Functional object When Pressing a Display Area When Selecting an Alarm/Event
Alarm/Event Display Yes No
Alarm/Event Summary & History No Yes
6-7

Omron NS Specifications

General

Power Supply	24 VDC
Display Size	5.7 to 12.1 inches (depending on the model)
Resolution	320 x 240 to 800 x 600
Touchscreen Type	Resistive
Display Type	TFT LCD
Communication Interfaces	RS-232C, RS-422/485, Ethernet, USB
Memory	Flash memory
Operating Temperature	0 to 50°C (depending on the model)
Storage Temperature	-20°C to 60°C
Protection Rating	IP65 (front panel)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
CPU	Proprietary Omron CPU (performance varies depending on the model)
