Section 10 Transferring Data 10-3 Data Transfer Using SPMA
NS-Designer Operation Manual
Settings on the Computer
Start up CX-Programmer.
1. Set the IP address of the PT in the IP Address on the Network Settings - Driver Tab Page.
2. Click the Network Tab and make the following settings.
Item Setting
FINS Source Address – Network (between
computer and PT)
1
FINS Destination Address – Network (be-
tween PT and PLC)
3
Node 4
10-56
To Next Page
