Section 13 Multi-language Display 13-2 Creating Multi-language Display Screens
NS-Designer Operation Manual NS-Designer Operation Manual NS-Designer Operation Manual
played. Restart Windows.
The fonts required to display Chinese characters will be displayed.
In this example, Simplified Chinese was added. Use the same procedure to add Traditional Chinese or
Hangul. Select Traditional Chinese and Korean in the list box.
2. Adding the Input Locale
1. Open Control Panel – Regional Options, select the Input Locales Tab Page, click the Add Button,
and add Chinese under Input locale.
• In Windows XP, open Control Panel – Regional Options, and select the Languages Tab
Page. Click the Details Button under Text services and input languages and add Chinese.
There are several types of Chinese input system (IME). In this example, the input system
MS-PinYin98 is selected.
Click the OK Button.
2. Switch between input locales is automatically set under Hot keys for input locales. Also the Enable
indicator on taskbar option at the bottom of the window is automatically selected. If the setting is
None, change the setting with the Change Key Sequence Button (Key Settings Button in Win-
dows XP).
13-5

Omron NS Specifications

General

Power Supply	24 VDC
Display Size	5.7 to 12.1 inches (depending on the model)
Resolution	320 x 240 to 800 x 600
Touchscreen Type	Resistive
Display Type	TFT LCD
Communication Interfaces	RS-232C, RS-422/485, Ethernet, USB
Memory	Flash memory
Operating Temperature	0 to 50°C (depending on the model)
Storage Temperature	-20°C to 60°C
Protection Rating	IP65 (front panel)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
CPU	Proprietary Omron CPU (performance varies depending on the model)
