7-2-4 Available Parts Libraries
There are basically two types of parts libraries.
Parts
Type Description Library name Standard parts
library
File name NV-series PT
Standard parts
library
These are the standard
parts libraries, provided
for each model.
Standard Parts
Libraries
Standard (NV3W) PART_V01.SPL For the NV3W
Standard (NV4W) PART_V12.SPL For the NV4W
Standard (NV3Q
Mono)
PART_V30M.SPL NV3Q mono-
chrome
Standard (NV3Q
Color)
PART_V30C.SPL NV3Q color
256-color
parts libraries
These libraries contain
parts that can be dis-
played in 256 colors.
There are three types of
parts: Bit Switches,
Function Switches, and
Lamps.
256-color lamp
library
Lamp (256Color) LAMP_COLOR.SPL NV3Q color
256-color switch
library
Switch (256Color) SW_COLOR.SPL
256-color func-
tion switch library
Function switch
(256Color)
FSW_COLOR.SPL
4,096-color
parts libraries
These libraries contain
parts that can be dis-
played in 4,096 colors.
These libraries enable
more visual expres-
sions than the 256-color
libraries.
4,096-color lamp
library
Lamp
(4,096Color)
LAMP_COLOR4096
.SPL
NV3Q color
4,096-color switch
library
Switch
(4,096Color)
SW_COLOR4096.S
PL
4,096-color func-
tion switch library
Function switch
(4,096Color)
FSW_COLOR4096.
SPL
Standard Library for an NV3W PT Standard Library for an NV4W PT
