82
Setting the NV Configuration from the NV-Designer Section 6-2
A comment can be registered for each unit number.
Click a unit number to select it, and then click the Comment Button. The fol-
lowing dialog box will be displayed.
Click the OK Button to register the comment. The registered comment will be
displayed when you return to the original dialog box.
Note Inputting comments (optional) for PLC unit numbers makes it easier to identify
the PLCs when setting addresses, e.g., for parts.
6-2-6 Auto-Paging Tab Page
Open the Auto-Paging Tab Page from the NV Configuration Dialog Box. The
auto-paging function is used to automatically switch to a specified screen after
a specified period of time has passed.
Item Description
1 Unit Number Displays the selected unit number.
The unit number cannot be changed.
2 Comment Input a comment for the unit number
(64 characters).
Item Description
Auto-Paging • Off
Screens will not be switched automatically.
•On
Screens will be automatically switched according to the set-
tings. The Setup Button will be enabled if the error code dis-
play is enabled. Click the Setup Button and set the screen
number to display, the display time, and jump destination.
To Next Page
