7-6 Lamps
7-6-1 Lamps
The display color of a lamp changes when the specified bit in the PLC turns
ON and OFF.
7-6-2 Default Settings of Lamps
7-6-3 Lamp Settings
Basic Setup ON/OFF bit Address 10.00
Color Setup
ON color
OFF color
Background
The color depends on the lamp part.
Operation Security Displays not restricted.
Label
When OFF
Text Not supported.
Font True Type (NV-Designer)
Position Left
Size: Number of dots 16
Language No. Language 0
Character style Not supported.
Color: Character Black
Background color Not supported.
When ON
Tex t
Font True Type (NV-Designer)
Position Left
Size: Number of dots 16
Language No. Language 0
Character style Not supported.
Color: Character Depends on the lamp.
Background color Not supported.
See Also
Setting methods are described while creating a screen.
Refer to 4-2-4 Creating Base Screens.
