Checking or Converting the Model Section 5-2
5-2 Checking or Converting the Model
5-2-1 NV Model Convert
Select Convert - NV Model Convert from the Tool Menu of the NV-Designer.
NV Model Conversion Table
Note Models can be converted only if the number of dots of the model
after the conversion is the same or larger than the model before
conversion. If the NV4W is changed from 8 shades of gray to 2
shades of gray or the NV3Q is changed from color to monochrome,
the NV-Designer will automatically reduce the number of shades
or colors.
After conversion
Before conversion
NV3W horizontal monochrome
NV3W vertical monochrome
NV4W with 2 shades of gray
NV4W vertical with 2 shades of gray
NV4W with 8 shades of gray
NV4W vertical with 8 shades of gray
NV3Q monochrome
NV3Q color
NV3W horizontal monochrome --- Not sup-
ported.
Sup-
ported.
Not sup-
ported.
Sup-
ported.
Not sup-
ported.
Sup-
ported.
Sup-
ported.
NV3W vertical monochrome Not sup-
ported.
--- Not sup-
ported.
Sup-
ported.
Not sup-
ported.
Sup-
ported.
Sup-
ported.
Sup-
ported.
NV4W with 2 shades of gray Not sup-
ported.
Not sup-
ported.
--- Not sup-
ported.
Sup-
ported.
Not sup-
ported.
Sup-
ported.
Sup-
ported.
NV4W vertical with 2 shades of
gray
Not sup-
ported.
Not sup-
ported.
Not sup-
ported.
--- Not sup-
ported.
Sup-
ported.
Not sup-
ported.
Not sup-
ported.
NV4W with 8 shades of gray Not sup-
ported.
Not sup-
ported.
Sup-
ported.
Not sup-
ported.
--- Not sup-
ported.
Not sup-
ported.
Sup-
ported.
NV4W vertical with 8 shades of
gray
Not sup-
ported.
Not sup-
ported.
Not sup-
ported.
Sup-
ported.
Not sup-
ported.
--- Not sup-
ported.
Not sup-
ported.
NV3Q monochrome Not sup-
ported.
Not sup-
ported.
Not sup-
ported.
Not sup-
ported.
Not sup-
ported.
Not sup-
ported.
--- Sup-
ported.
NV3Q color Not sup-
ported.
Not sup-
ported.
Not sup-
ported.
Not sup-
ported.
Not sup-
ported.
Not sup-
ported.
Sup-
ported.
---
