Omron NV Series - Switching Backlight Colors; Default Settings for Backlight Color

162
Switching Backlight Colors Section 8-1
8-1 Switching Backlight Colors
The initial settings for backlight colors of the PT can be set, and they can then
be changed from the PLC.
8-1-1 Default Settings for Backlight Color
1,2,3... 1. Check the backlight color.
2. Right-click on the base screen and select Screen Properties from the pop-
up menu. Or select Screen Properties from the PT Menu.
3. Set the backlight color.
4. Click the OK Button.
The current color is displayed
on the left end of the title bar.
Set the backlight.
Backlight: Red
Operation: Light
Note The backlight colors
depend on the model.
Refer to the following
table.
The color at the left end of the
title bar will change to red.
Note With the NV3W-
MR@@(@), NV4W-
MR@@, or NV3Q-
MR@@ the backlight
will be white when the
square on the left of the
title bar is green/white
and pink when the
square is orange/pink.
PT Backlight
color
Color setting Operation setting
Light Blink
NV3W-MG@@(@) 3 colors Green Orange Red Supported. Supported.
NV3W-MR@@(@) 3 colors White Pink Red Supported. Supported.
NV4W-MG@@ 3 colors Green Orange Red Supported. Supported.
NV4W-MR@@ 3 colors White Pink Red Supported. Supported.
NV3Q-MR@@ 3 colors White Pink Red Supported. Supported.
NV3Q-SW@@ --- No attribute No attribute
