NV-Designer Configuration Section 3-3
3-3-2 NV-Designer Configuration
Setting Method Select NV-Designer Configuration from the Tool Menu.
NV-Designer Configuration and Initial Values
Tab Description Item Initial Value
Drive Specify the data folder of the parts
libraries that are used by the NV-
Designer.
Parts Library Installation folder/STP
File Enables/disables automatic
backup and sets the backup inter-
val.
Current Folder C:\documents and set-
tings\ UserName\
Auto-Backup: Every 5 to 30 minutes Not selected.
Grid Displays/hides the grid, enables/
disables snapping to the grid, and
sets the grid interval, color, etc.
Display: On/Off Off
Pitch Default/Setup Standard
Setup X direction NV3W: 8 dots
NV4W: 8 dots
NV3Q: 20 dots
Y direction NV3W: 8 dots
NV4W: 8 dots
NV3Q: 20 dots
Snap: Enable/Disable Disabled
Color: Grid Black
Screen NV-Designer Screen Display Set-
tings
Toolbar: Display/Hide View
Graphic Bar: Display/Hide View
Zoom Box: Display/Hide Hide
Parts Informa-
tion
Parts No. Hide
Parts Attribute Hide
Fill Pointer Display/Hide View
Fill Pointer Color Black
Tips Display Shows Tips before Sav-
ing a Project.
View
Graphic Sets the drawing method for cir-
cles and ovals.
Circle/Oval: Start from Center Point/Start
from Top Left Corner
Start from Top Left Cor-
ner
Language Sets the language to use by
default.
Default Character Set: Japanese
Menu and Dialog Language: Japanese,
English or Korean
English
Multi-Language Exchange: On/Off Off
