Omron NV Series - Write Address Default Settings; Write Address Setup Example

171
Write Address Data Section 8-4
8-4-3 Write Address Default Settings
8-4-4 Write Address Setup Example
1,2,3... 1. Select Write Address from the PT Menu.
2. Display the Write Address Dialog Box.
3. Display the Write Address Dialog Box.
Condition Specified Screen Valid only for specified screens 0
Condition 1 Operational under Valid Condition 10.00 ON
Condition 2 Always Operational
Operation Operation mode Set 10.00
Creating a Sample Screen
When the Operation Button
(CIO 10.00) is turned ON, the
frequency (D100) is incre-
mented by 1.
Select the first item in the list
and click the Settings Button.
Make the following settings on
the Condition Tab Page.
Specified
Screen:
Condition 1:
Condition 2:
All Screens
Operational under
Valid Condition
Always Opera-
tional
If multiple conditions are
selected, an AND condition is
used.
