Recipes Section 8-5
8-5-3 Using Recipes
1,2,3... 1. Start the Recipe Menu.
2. Click the NV Config Button to setup the PT Configuration.
3. Change the Data/Recipe Setting.
Additional Information
• Write, read, and deletion cannot be performed simultaneously. If all bits are
ON, write, read, or deletion will be performed in that order.
• If all flags are OFF, either write, read, or deletion can be performed.
Select Recipe from the PT
Menu.
Make the following settings,
and then click the OK Button.
Recipe:
Control Address:
On
W20
Up to 100 (No. 0 to 63) recipe
files can be created.
Select file 0 from the recipe
list and click the Open Button.
Change the Data/Recipe Set-
ting as follows:
Data Sets (Rows) Entry
Address Number:
Recipes (Columns):
10
3
To Next Page
