NV-Designer Window Names and Menus Section 3-2
Continuous Line Button
Creates continuous lines.
Rectangle Button
Creates a rectangle.
Circle/Oval Button
Creates a circle or oval.
Arc/Elliptical Arc Button
Creates a circular or oval arc.
Curve Button
Creates a curved line.
Segment/Oval Segment Button
Creates a circular or oval sector.
Rounded Rectangle Button
Creates a square with rounded corners. The radius of the rounded corners
can be changed in the line settings.
Polygon Button
Creates a polygon.
Fill Button
Fills areas enclosed by lines and graphics with a color.
Character Type Button
Sets the size and style (bold, outline, underline) of characters.
Color Button
Changes the color of character strings and graphics.
Line Type Button
Sets the line thickness and type.
