8 At this point, a confirmation dialog box is displayed to check whether the registered tag names
are used as the tag set names. A tag set can contain up to eight tags, but tag sets are regis-
tered with one tag per tag set if the tag names are registered as tag set names. In this case,
click the Yes
Button.
If the No Button is clicked, you can add more tags to the tag set. Refer to step 8 in Changing
and Registering Tag Sets
for details on how to register new tags first and add more tags to the
tag set later.
l
Changing and Registering Tag Sets
1 The following dialog box is displayed when the tags in the Edit Tags are registered directly as
tag sets.
2 If an input tag is already registered in an input tag set, and you want to change its registration
to a dif
ferent input tag set, it is necessary to delete the tag from the tag set in which it was origi-
nally registered.
Open the
Edit Device Parameters Dialog Box, select the tag set containing the tag that you
want to delete on the Tag Sets Tab Page, and click the Delete Button. (If there are other tags
registered in the tag set, it is possible to delete just one tag by selecting the tag that you want
to delete in the Edit Tag Set Dialog Box and clicking the
Button.)
9 Tag Data Link Functions
9-25
NX-series EtherNet/IP Unit User's Manual (W627)
9-2 Setting Tag Data Links
9
9-2-4 Creating Tags and Tag Sets

Omron NX Series Specifications

General

Programming Languages	Ladder, Structured Text, Function Block Diagram, Sequential Function Chart
Communication Ports	Ethernet, USB, RS-232C, RS-485
Memory Capacity	Varies by model
Program Memory	Varies by model
Data Memory	Varies by model
Operating Temperature	0°C to 55°C
Power Supply	24 VDC
Ethernet Ports	1 or 2 ports (depending on model)
USB Ports	1 or 2 ports (depending on model)
Dimensions	Varies by model
Weight	Varies by model
