2-2 External and Mounting Hole Dimensions
2
Standard Models and Dimensions
External Regeneration Resistor Dimensions
 External Regeneration Resistor
R88A-RR08050S/-RR080100S
R88A-RR22047S1
R88A-RR50020S
20
t1.2 104
122
130
43.5
28
4.2
6
Thermal switch output
500
1.5 dia. (0.3mm
2
)
3 dia. (0.75mm
2
)
20
t1.2 200
220
230
62 48
4.2
6
500
Thermal switch output
1.5 dia. (0.3mm
2
)
3 dia. (0.75mm
2
)
360
386
402
4325 10
78
76
40
5.3
t1.6
