3-6 External Regeneration Resistor Specifications
3
Specifications
3-6 External Regeneration Resistor
Specifications
External Regeneration Resistor Specifications
 R88A- RR08050S
 R88A-RR080100S
 R88A-RR22047S1
Model Resistance
Nominal
capacity
Regeneration
absorption for 120°C
temperature rise
Heat radiation
condition
Thermal switch
output specifications
R88A-
RR08050S
50  80 W 20 W
Aluminum,
350  350,
Thickness: 3.0
Operating temperature:
150C  5% NC contact
Rated output (resistive
load):
125 VAC, 0.1 A max.
30 VDC, 0.1 A max.
(minimum current: 1 mA)
Model Resistance
Nominal
capacity
Regeneration
absorption for 120°C
temperature rise
Heat radiation
condition
Thermal switch
output specifications
R88A-
RR080100S
100  80 W 20 W
Aluminum,
350  350,
Thickness: 3.0
Operating temperature:
150C  5% NC contact
Rated output (resistive
load):
125 VAC, 0.1 A max.
30 VDC, 0.1 A max.
(minimum current: 1 mA)
Model Resistance
Nominal
capacity
Regeneration
absorption for 120°C
temperature rise
Heat radiation
condition
Thermal switch
output specifications
R88A-
RR22047S1
47  220 W 70 W
Aluminum,
350  350,
Thickness: 3.0
Operating temperature:
150  C  5  C NC contact
Rated output (resistive
load):
250 VAC, 0.2 A max.
42 VDC, 0.2 A max.
(minimum current: 1 mA)
