2-2 External and Mounting Hole Dimensions
2
Standard Models and Dimensions
Parameter Unit Dimensions
R88A-PR02G Hand-held Parameter Unit
Mini DIN 8-pin
MD connector
(62)
(24)
(15)
(1500)
M3 (depth: 5)
(114)
(15)
