5-13 Sequence Output Signals
Operating Functions
5
5-13 Sequence Output Signals
Function
 Sequence output signals that output the Servo Drive status.
Parameters Requiring Settings
 CN1 Control Output Signals
Parameter
No.
Parameter name Explanation Reference page
Pn112
General-purpose
Output 1 Function
Selection
Selects the function for general-purpose output 1 (OUTM1). 5-83
Pn113
General-purpose
Output 2 Function
Selection
Selects the function for general-purpose output 2 (OUTM2). 5-83
Pn114
General-purpose
Output 3 Function
Selection
Selects the function for general-purpose output 3 (OUTM3). 5-83
Pin
No.
Symbol Name Function/Interface
15 /ALM
Alarm Output
The output is OFF when an alarm is generated in the
Servo Drive.
16 ALMCOM
29 OUTM2
General-purpose
Output 2 (READY)
This is a general-purpose output. The function for this
output is selected by changing the parameter.
Refer to Output Signal Assignment Details on the next
page.
30 OUTM2COM
31 OUTM3
General-purpose
Output 3 (CLIM)
32 OUTM3COM
36 OUTM1
General-purpose
Output 1 (BKIR)
35 OUTM1COM
