2-68
2-2 External and Mounting Hole Dimensions
2
Standard Models and Dimensions
Reactor Dimensions
3G3AX-DL2002
3G3AX-DL2004
Ground terminal
(M4)
66
56
72
90
Four, 5.2 × 8
Two, M4
98
85
66
56
72
90
98
95
Ground terminal
(M4)
Two, M4
Four, 5.2 × 8
