2-2 External and Mounting Hole Dimensions
2
Standard Models and Dimensions
3G3AX-DL2007
3G3AX-DL2015
66
56
72
90
98
105
Ground terminal
(M4)
Two, M4
Four, 5.2 × 8
66
56
72
90
98
115
Ground terminal
(M4)
Two, M4
Four, 5.2 × 8
